The waterproof breather membrane also excels in resistance to detergents, ensuring long-lasting performance in various applications. It is highly suitable for use in clothing and footwear, where breathability and moisture management are essential. Additionally, its recyclability aligns with environmental sustainability goals, making it an eco-friendly option for manufacturers seeking to reduce their carbon footprint.
Products Description
- High Breathability: Breathability refers to the material's ability to transmit water vapor. This TPEE film likely exhibits excellent breathability, contributing to regulating skin surface humidity and enhancing comfort.
- Good resistance: to creep, impact, fatigue, high impact strength, and excellent high/low temperature performance.
- High tensile strength: waterproof breather membrane boasts excellent tensile properties, maintaining stability under stress, resistant to tearing or deformation.
- Abrasion Resistance: It may possess good abrasion resistance, capable of withstanding friction and wear, maintaining the product's appearance and performance.
- Good resilience and excellent rebound elasticity.
- Good chemical resistance, oil/water resistance, excellent resistance to chemical solvents, resistance to thermal aging, UV resistance, and good weather resistance.
- Environmental Friendly and recyclability: waterproof breather membrane could be an environmentally friendly material, meeting environmental standards, and being recyclable.
Specifications
Thickness: 5/8/10/12/15um
Width: 1600-1700mm
Color: Natural/White/Any other colors customizable
|
TEST ITEM |
TEST METHOD |
UNIT |
TEST VALUE |
||
|
Thickness |
GB/T 6672 |
um |
10 |
12 |
15 |
|
Appearance |
Visual Inspection |
/ |
White |
||
|
Tensile Strength |
GB/T 13022 |
MPa |
CD: 15 MD: 14 |
CD: 15 MD: 14 |
CD: 16 MD: 14 |
|
Elongation at Break |
% |
CD: 630 MD: 640 |
CD: 633 MD: 650 |
CD: 683 MD: 680 |
|
|
Wet Tension |
GBT 14216-1993 |
mN/m |
50-58 |
||
|
Hydrostatic Pressure |
JIS L1092.1998 A |
MmH2O |
>10000 |
||
|
Moisture Permeability |
GB/T 12704.1 Hygroscopic method |
g/(m2*24h) |
7000-7500 |
||
|
JIS L 1099-2012 A1 |
7500-8000 |
||||
|
JS L 1099-2012 B1 |
210,000-220,000 |
||||
|
ASTM E96-2000BW |
12,000-13,000 |
||||
|
IS0 11092-1993 Ret |
m2Pa/W |
0.4-0.6 |
|||
|
IS0 15496-2004 |
g/(m2Pa* 24h). g/(m2*24h) |
1.45-1.48 48,000-50,000 |
|||
|
BS 7209-1990 |
% |
95-100 |
|||
|
Temperature Range |
/ |
℃ |
-40~200 |
||
